Customizable Pure Metal Fiber Fabric Technical Textile Length Can be Customized
| Place of Origin | China |
|---|---|
| Brand Name | Huitong |
| Certification | ISO9001-2015,ISO14001-2015,ISO25001,ISO16949 |
| Model Number | Pure Metal Fiber Fabric |
| Minimum Order Quantity | 1m2 |
| Price | USD EURO |
| Packaging Details | customized packaging as required. |
| Delivery Time | 15-30days |
| Payment Terms | T/T, D/A, L/C, T/T, Western Union |
| Supply Ability | 1000m2/month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Materials | FeCrAl/316L | Length | Can Be Customized As Request |
|---|---|---|---|
| Warranty | ≥3 Years | Product Name | Pure Metal Fiber Fabric |
| Brand | Huitong | ||
| Highlight | Customizable Metal Fiber Fabric,Pure Metal Fiber Fabric,Technical Textile Metal Fiber Fabric |
||
Product Description
Gas Burner---Metal Fiber Fabric Solutions
【Description】
Pure metal fiber fabrics are divided into two types, knitted and woven, composed of 100% metal fiber or metal fiber / special chemical fiber (such as aramid, PbO, etc.) blended yarn, which has corrosion resistance, high temperature resistance (stainless steel,600-700 °C,FeCrAl,800-900°C) and good softness. The temperature resistance of the blended fabric is different depending on the blended fiber.In addition to the above commonalities, knitted products have high elasticity and high strength of woven products.
【Application】
Knitted pure metal fiber fabrics can be applied to high temperature environments such as the glass industry.
Woven pure metal fiber fabric can be used in automotive glass, vacuum tube and glass processing, high temperature flue gas filter bags and other high temperature environments.
【Parameters】
1.Wide knitted fabric
【Application】
Knitted pure metal fiber fabrics can be applied to high temperature environments such as the glass industry.
Woven pure metal fiber fabric can be used in automotive glass, vacuum tube and glass processing, high temperature flue gas filter bags and other high temperature environments.
【Parameters】
1.Wide knitted fabric
| Item | Width(mm) | ||
| 1800 | 1900 | 1700 | |
| SUS type | SUS316L | ||
| Count | 11/2S | ||
| Thickness(mm) | 0.8-1.6 | ||
| Weight/Square Meter(g/㎡) | 800-1300 | ||
| Deviation per square weight | ±5% | ||
2.Wide woven fabric
| Item | Width(mm) | |||
| 1000 | 1200 | 1500 | ||
| SUS Type | SUS316L | |||
| Count | 16/25 | |||
| Thickness (mm) |
Plain Weave | 0.35 | ||
| Twill | 0.5 | |||
| Weight/Square Meter(g/㎡) | Plain Weave | 0.35 | ||
| Twill | 0.5 | |||
| Deviation per square weight | ±5% | |||
